99-03 Grand Am parts : Body & Structure/Doors & Glass/Interior Trim & Components
Pillars, Rockers & floor
 1 Uniside Assy - 99-03 R GM# 12335380 - 99-03 L GM# 12335381 Windshield frame 2 outer - 99-03 included with inner frame and included with uniside assy. 3 Inner - 99-03 R GM# 22654906 - 99-03 L GM# 22654907 4 Inner pillar - 99 R GM# 22632124 - 99 L GM# 22604779 - 00-03 R GM# 22632124 - 00-03 L GM# 22669225 5 Upper reinf - 99-03 included with Uniside assy 6 Lower reinf - 99-03 included with Uniside assy 7 reinforcment - 99-03 R not serviced 8 lower brace - 99-03 R GM# 22640806 - 99-03 L GM# 22640807 9 Baffle - 99-03 included with Uniside assy 10 pillar reinforcment - 99-03 R GM# 22645624 - 99-03 L GM# 22645625 11 stricker reinf - 99-03 included with Uniside assy Uniside 4 door  1 Uniside Assy - 99-01 R GM# 12335378 - 99-01 L GM# 12335379 - 02-03 R GM# 88952084 - 02-03 L GM# 88952085 Windshield frame 2 Outer - 99-03 included with Uniside assy 3 inner - 99-03 R GM# 22654906 - 99-03 L GM# 22654907 4 Extension Side roof rail - 99-03 R GM# 22640762 - 99-03 L GM# 22640763 5 inner pillar - 99 R GM# 22632124 - 99 L GM# 22604779 - 00-03 R GM# 22632124 - 00-03 L GM# 22669225 6 Upper reinf - 99-03 included with Uniside assy 7 Lower Reinf - 99-03 included with Uniside assy 8 Lower brace - 99-03 R GM# 22640806 - 99-03 L GM# 22640807 9 baffle - 99-03 included with Uniside assy 10 Anchor plate door hinge All - 99-01 B GM# 22606325 Upper - 02-03 B GM# 22642438 Lower - 02-03 B GM# 22654116 11 Center pillar - 99-02 R GM# 22658744 - 99-02 L GM# 22658745 - 03 not listed 12 Pillar reinf - 99-03 included with Uniside assy 13 stricker retainer - 99 GM# 22640524 00-03 not sericed Floor & Rails  1 front floor pan - 99-03 not serviced 2 frnt c'member - 99-03 not serviced 3 rear crossmember - 99-03 not serviced 4 Outer reinf - 99-03 R GM# 22640798 - 99-03 L GM# 22640799 5 inner rocker - 99-02 R GM# 22615496 - 99-02 L GM# 22615497 -03 B not listed Exterior trim  1 SE 1st design - 99 R GM# 12365254 - 99 L GM# 12365255 2 nd design - 99-03 R GM# 12463280 - 99-03 L GM# 12463281 2 GT 2 door - 99-03 R GM# 12365256 - 99-03 L GM# 12365257 4 door - 99-03 R GM# 12365258 - 99-03 L GM# 12365259 protector - 99-03 B GM# 12463301 3 clip - 99-03 GM# 22603384 retainer outer 4 upper - 99-03 GM# 10246149 5 lower - 99-03 GM# 10246149 6 inner - 99-03 GM# 15679091 Interior trim  2 door 1 w/s pillar trim grey - 99-03 R GM# 22669322 - 99-03 L GM# 22669323 neutral - 99-03 R GM# 22669320 - 99-03 L GM# 22669321 Oak - 99 R GM# 22618658 - 99 L GM# 22618659 Center plr trim 2 upper neutral - 99-03 R GM# 22617716 - 99-03 L GM# 22617717 pewter - 99-03 R GM# 22617718 - 99-03 L GM# 22617719 Oak - 99 R GM# 22617720 - 99 L GM# 22617721 3 Lower Neutral - 99-03 R GM# 22644834 - 99-03 L GM# 22644835 Grey - 99-03 R GM# 22655318 - 99-03 L GM# 22655319 Oak - 99 R GM# 22655320 - 99 L GM# 22655321 Sill plate 4- 2 door - 99-03 R GM# 22617982 - 99-03 L GM# 22617983 4 door 5- Front - 99-03 R GM# 22617980 - 99-03 L GM# 22617981 6 rear - 99-03 B GM# 22617979 Carpet retainer 7 2 door neutral - 99-03 R GM# 22615952 - 99-03 L GM# 22615953 grey - 99-03 R GM# 22615950 - 99-03 L GM# 22615951 Oak - 99 R GM# 22615954 - 99 L GM# 22615955 8 4 door front neutral - 99-03 R GM# 22615964 - 99-03 L GM# 22615965 grey - 99-03 R GM# 22615966 - 99-03 L GM# 22615967 Oak - 99 R GM# 22615968 - 99 L GM# 22615969 9 4 door rear neutral - 99-03 R GM# 22617640 - 99-03 L GM# 22695687 Grey - 99-03 R GM# 22617638 - 99-03 L GM# 22695685 Oak - 99 R GM# 22611964 - 99 L GM# 22611965 Doors 2 Door  1 Door Shell - 99-03 R GM# 22702412 - 99-03 L GM# 22702415 anchor plate Door hinge - 99-01 B GM# 22606325 2 Outer panel - 99-03 R GM# 22614328 - 99-03 L GM# 22614329 3 Reinforce bar - 99-03 included in door shell 4 Support bar - 99-03 included in door shell 5 Weatherstrip on body pewter - 99-03 B GM# 22626558 neutral - 99-03 B GM# 22626560 Oak - 99 B GM# 22614276 Exterior trim 2 door  1 seal strip Upper window frame GT - 99-03 R GM# 22632174 - 99-03 L GM# 22632175 SE - 99-02 R GM# 22632170 - 99-02 L GM# 22632171 2 Belt w'strip GT - 99-03 R GM# 22682292 - 99-03 L GM# 22682293 SE - 99-02 R GM# 22682290 - 99-02 L GM# 22682289 3 Applique - 99-03 R GM# 22617148 - 99-03 L GM# 22617149 4 bolt - 99-01 GM# 12337991 - 02-03 GM# 11517752 Body side molding 5 GT - 99-03 R GM# 12365260 - 99-03 L GM# 12365261 6 SE - 99-02 R GM# 12365268 - 99-02 L GM# 12365269 Name plate 7 "Grand", GT model Gold - 99 GM# 22602346 White - 99-02 GM# 22636894 Red - 99-02 GM# 22636895 Mantra green - 99 GM# 22636898 Laguna green - 00-02 GM# 22619235 Black - 99-02 GM# 22650199 Silvermist - 00 GM# 22623633 All - 03 not listed "grand" SE model Chrome - 99-02 GM# 22657236 8 "AM", GT model Gold - 99 GM# 22602347 white - 99-02 GM# 22636900 red - 99-02 GM# 22636901 mantra green - 99-01 GM# 22636904 laguna green - 00-02 GM# 22619236 black - 99-02 GM# 22650200 silvermist - 00 GM# 22623640 All -03 mot listed "AM" , SE model Chrome - 99-02 GM# 22635841 9 "SE" Chrome - 99-02 GM# 22657237 10 "GT" Grey - 99-02 GM# 22636906 - 03 not listed Out side Mirror  1 mirror Assy manual - 99-01 R GM# 22613598 - 99-01 L GM# 22613599 - 02 R GM# 22676402 - 02 L GM# 22676403 - 03 not listed Power Black - 99-01 R GM# 22613596 - 99-01 L GM# 22613597 - 02 R GM# 22688826 - 02 L GM# 22688827 Painted - 99-02 R GM# 22613584 - 99-02 L GM# 22613585 - 03 R GM# 22686740 - 03 L GM# 22686741 2 Insulator - 99-03 B GM# 22643123 3 Mirror glass - 99-01 R GM# 12365280 - 99-01 L GM# 12365281 SE - 02 R GM# 88892808 - 02 L GM# 88892809 GT - 02 R GM# 12365280 - 02 L GM# 12365281 - 03 R GM# 88891916 - 03 L GM# 88891917 Glass & Hardware  2 Door 1 Door glass GM - 99-03 R GM# 22689002 - 99-03 L GM# 22689001 NAGS - 99-03 R DD09428GTY - 99-03 L DD09429GTY 2 Run channel - 99-03 R GM# 22623408 - 99-03 L GM# 22623407 3 retainer - 99-03 R GM# 22612648 - 99-03 L GM# 22612649 4 Belt w'strip - 99-03 R GM# 22615486 - 99-03 L GM# 22615487 5 Regulator manual windows - 99-02 R v22697438 - 99-02 L GM# 22697439 - 03 not listed power windows - 99-03 R GM# 22697436 - 99-03 L GM# 22619443 6 Window Handle - 99-03 B GM# 22648611 7 cover plate - 99-03 GM# 20529400 8 Cover regulator opening - 99-03 B GM# 22615772 9 Water deflector - 99-02 R GM# 22618424 - 99-02 L GM# 22618425 - 03 R GM# 22694110 - 02 L GM# 22694111 Lock & Hardware  1 Lock - 99-03 R GM# 16633858 - 99-03 L GM# 16633859 2 lock actuator - 99-02 R GM# 25664287 - 99-02 L GM# 25664288 - 03 B not listed 3 striker - 99-03 B GM# 16629888 4 spacer - 99-03 GM# 16621670 5 washer - 99-03 GM# 22597807 6 anchor plate - 99-03 B 22645208 7 bolt - 99-03 9442471GM# Lock Rod 8 to inside handle - 99-03 R GM# 22640938 - 99-03 L GM# 22640939 9 to Out side handle - 99-03 R GM# 22626880 - 99-03 L GM# 22626881 10 To lock - 99-03 R v22616674 - 99-03 L GM# 22610177 11 to cylinder - 99-01 R GM# 22610179 - 99-01 L v22610178 - 02-02 R GM# 22626600 - 02-03 L GM# 22626601 Clip 12 inside handle - 99-03 GM# 22606324 13 outside handle - 99-03 GM# 16675980 14 Handle inside pewter - 99-03 R GM# 22616260 - 99-03 L GM# 22616261 neutral - 99-03 R GM# 22657422 - 99-03 L GM# 22657423 Oak - 99 R GM# 22657424 - 99 L GM# 22657425 15 Handle outside - 99-03 R GM# 22670068 - 99-03 L GM# 22670069 16 Lock Cylinder - 99-03 B GM# 12457619 17 spring - 99-03 GM# 12503691 18 gasket - 99-03 B GM# 22600784 19 Lock pawl - 99-03 R GM# 2852086 - 99-03 L GM# 2852087 20 retainer - 99-03 GM# 2852074 21 Upper Hinge - 99-03 R GM# 22615856 - 99-03 L GM# 22615857 22 Lower Hinge - 99-03 R v22615856 - 99-03 L GM# 22615857 23 Door check - 99-03 B GM# 22702307 24 grommet - 99-03 GM# 22602300 Interior trim  1 Door trim panel cloth - 99 R GM# 22612112 - 99 L GM# 22612113 - 00 R GM# 22628562 - 00 L GM# 22628563 Pewter - 01-03 R GM# 22666486 - 01-03 L GM# 22666487 neutral - 01-03 R GM# 22666484 - 01-03 L GM# 22666485 leather - 99-00 R GM# 22612118 - 99-00 L GM# 22612119 2 retainer - 99-03 B GM# 22605931 3 ABsorber - 99-03 R GM# 22643134 - 99-03 L GM# 22643135 4 Pull handle pewter - 99-03 R GM# 22655514 - 99-03 L GM# 22655515 neutral - 99-03 R GM# 22646410 - 99-03 L GM# 22646411 Oak - 99 R GM# 22655520 - 99 L GM# 22655521 5 bracket - 99-03 R GM# 22656032 - 99-03 L GM# 22656033 6 Map pocket - 99-03 B included with door trim 7 speaker grill - 99-01 B GM# 22656023 - 02-03 B GM# 22666492 8 Handle bezel pewter - 99-01 R GM# 22617654 - 99-01 L GM# 22617655 - 02-03 R GM# 22666504 - 02-03 L GM# 22666505 Neutral - 99-01 R GM# 22617656 - 99-01 L GM# 22617657 - 02-03 R GM# 22666506 - 02-03 L GM# 22666507 Oak - 99 R GM# 22617658 - 99 L GM# 22617659 9 Upper trim panel w/o speaker pewter - 99-01 R GM# 22614772 - 99-01 L GM# 22614773 neutral - 9-01 R GM# 22614770 - 99-01 L GM# 22614771 Oak - 99 R GM# 22614774 - 99 L GM# 22614775 W/speaker pewter - 99-03 R GM# 22695596 - 99-03 L GM# 22695597 neutral - 99-03 R GM# 22695594 - 99-03 L GM# 22695595 Oak - 99 R GM# 22614766 - 99 L GM# 22614767 10 switch panel Manual windows - 99-00 R GM# 22658261 - 99-00 L GM# 22658257 - 01-03 R GM# 22663002 - 01-03 L GM# 22663003 power windows - 99-00 R GM# 22658260 - 99-00 L GM# 22658259 - 01-03 R GM# 22663004 - 01-03 L GM# 22663006 11 retainer - 99-03 B 22603516 12 switch bezel - 99-03 included with switch panel 13 mirror switch - 99-00 GM# 12369209 - 01-03 GM# 22624805 14 Lock switch - 99-01 B GM# 22657207 - 02-03 B GM# 22624806 15 Window switch - 99-02 R GM# 22591937 - 99-02 L GM# 22588179 - 03 not listed 16 trunk switch - 99-00 GM# 22601764 - 01-03 GM# 22624803 17 reflector - 99-03 B GM# 22612756 Front 4 door front Door & components  1 door shell - 99-02 R GM# 22702414 - 99-02 L GM# 22621899 -03 not listed anchor plate door hinge - 99-00 B GM# 22606325 2 Outer panel - 99-03 R GM# 22614332 - 99-03 L GM# 22614333 3 reinforce bar outer & inner - 99-03 B included with door shell 4 support bar - 99-03 B included with door shell 5 Weatehr strip On body pewter - 99-03 B GM# 22626562 neutral - 99-03 B GM# 22626564 Oak - 99 B GM# 22626563 Exterior Trim  1 Seal strip upper window frame GT - 99-03 R GM# 22632176 - 99-03 L GM# 22632177 SE - 99-03 R GM# 22632172 - 99-03 L v22701125 2 Belt weather strip GT - 99-03 R GM# 22682298 - 99-03 L GM# 22682299 SE - 99-03 R GM# 22682296 - 99-03 L GM# 22682295 3 Applique - 99-03 R GM# 22617150 - 99-03 L GM# 22617151 4 bolt - 99-01 GM# 12337991 - 02-03 GM# 11517752 Body side mldg 5 GT - 99-03 R GM# 12365262 - 99-03 L GM# 12365263 6 SE - 99-02 R v12365270 - 99-02 L GM# 12365271 - 03 R GM# 88898959 - 03 L GM# 88898960 Name plate 7 "GRAND", GT model gold - 99 GM# 22602346 white - 99-02 GM# 22636894 red - 99-02 GM# 22636895 mantra green - 99 GM# 22636898 laguna green - 00-02 GM# 22619235 black - 99-02 GM# 22650199 silvermist - 00-01 GM# 22623633 "GRNAD", SE model Chrome - 99-02 GM# 22657236 8 "AM", GT model gold - 99-00 GM# 22602347 white - 99-02 GM# 22636900 red - 99-02 GM# 22636901 mantra green - 99 GM# 22636904 laguna green - 00-02 GM# 22619236 black - 99-02 GM# 22650200 silvermist - 00 GM# 22623640 "AM", SE model chrome - 99-02 GM# 22635841 - 03 not listed 9 "SE" chrome - 99-02 GM# 22657237 10 "GT" grey - 99-02 GM# 22636906 Power mirror 2 & 4 Door models  1 mirror Assy manual - 99-01 R GM# 22613598 - 99-01 L GM# 22613599 - 02 R GM# 22676402 - 02 L GM# 22676403 - 03 not listed Power Black - 99-01 R GM# 22613596 - 99-01 L GM# 22613597 - 02 R GM# 22688826 - 02 L GM# 22688827 Painted - 99-02 R GM# 22613584 - 99-02 L GM# 22613585 - 03 R GM# 22686740 - 03 L GM# 22686741 2 Insulator - 99-03 B GM# 22643123 3 Mirror glass - 99-01 R GM# 12365280 - 99-01 L GM# 12365281 SE - 02 R GM# 88892808 - 02 L GM# 88892809 GT - 02 R GM# 12365280 - 02 L GM# 12365281 - 03 R GM# 88891916 - 03 L GM# 88891917 Glass & Hardware  1 Door glass GM - 99-03 R GM# 22689004 - 99-03 L GM# 22689003 NAGS - 99-03 R DD09435GTY _ 99-03 L DD09436GTY 2 Run channel - 99-03 R GM# 22623404 - 99-03 L GM# 22623405 3 retainer - 99-03 R GM# 22612648 - 99-03 L GM# 22612649 4 Belt weatherstrip - 99-03 R GM# 22615488 - 99-03 L GM# 22615489 5 Regulator manual windows - 99-03 R GM# 22697442 - 99-03 L GM# 22697443 power windows - 99-03 R GM# 22697440 - 99-03 L GM# 22619447 6 Window handle - 99-03 B GM# 22648611 7 cover plate - 99-03 GM# 20529400 8 cover, regulator opening - 99-03 B GM# 22615772 9 water deflector - 99-02 R GM# 22618426 - 99-02 L GM# 22618427 - 03 R GM# 22694112 - 03 L GM# 22694113 Lock & Hardware frnt door 1 Lock - 99-03 R GM# 16633858 - 99-03 L GM# 16633859 2 lock actuator - 99-02 R GM# 25664287 - 99-02 L GM# 25664288 - 03 B not listed 3 striker - 99-03 B GM# 16629888 4 spacer - 99-03 GM# 16621670 5 washer - 99-03 GM# 22597807 6 anchor plate - 99-02 B GM# 22645207 7 bolt - 99-03 GM# 9442471 Lock Rod 8 to inside handle - 99-03 R GM# 22609620 - 99-03 L GM# 22609621 9 to Out side handle - 99-03 R GM# 22626880 - 99-03 L GM# 22626881 10 To lock - 99-03 R GM# 22616676 - 99-03 L GM# 22610177 11 to cylinder - 99-00 R GM# 22620512 - 99-00 L GM# 22620513 - 01-02 R GM# 22626602 - 01-03 L GM# 22626603 Clip 12 inside handle - 99-03 GM# 22606324 13 outside handle - 99-03 GM# 16675980 14 Handle inside pewter - 99-03 R GM# 22616260 - 99-03 L GM# 22616261 neutral - 99-03 R GM# 22657422 - 99-03 L GM# 22657423 Oak - 99 R GM# 22657424 - 99 L GM# 22657425 15 Handle outside - 99-03 R GM# 22670068 - 99-03 L GM# 22670069 16 Lock Cylinder - 99-03 B GM# 12457619 17 spring - 99-03 GM# 12503691 18 gasket - 99-03 B GM# 22600784 19 Lock pawl - 99-03 R GM# 2852086 - 99-03 L GM# 2852087 20 retainer - 99-03 GM# 2852074 21 Upper Hinge - 99-03 R GM# 22615856 - 99-03 L GM# 22615857 22 Lower Hinge - 99-03 R GM# 22615856 - 99-03 L GM# 22615857 23 Door check - 99-03 B GM# 22700046 24 grommet - 99-03 GM# 22602300 Interior trim 4 dr frnt door  1 door trim panel cloth neutral - 99 R GM# 22612082 - 99 L GM# 22612083 - 00 R GM# 22628556 - 00 L GM# 22628557 - 01-03 R GM# 22666478 - 01-03 L GM# 22666479 Grey - 01-03 R GM# 22666480 - 01-03 L GM# 22666481 Leather - 99-00 R GM# 22612090 - 99-00 L GM# 22612091 2 retainer - 99-03 B GM# 22605931 3 Pull handle pewter - 99-03 R GM# 22655514 - 99-03 L GM# 22655515 neutral - 99-03 R GM# 22646410 - 99-03 L GM# 22646411 Oak - 99 R GM# 22655520 - 99 L GM# 22655521 4 bracket - 99-03 R GM# 22656032 - 99-03 L GM# 22656033 5 Map pocket - 99--03 B included with door trim 6 speaker grill - 99-00 B GM# 22656023 - 01-03 B GM# 22666492 7 Handle bezel pewter - 99-01 R GM# 22617654 - 99-01 L GM# 22617655 - 02-03 R GM# 22666504 - 02-03 L GM# 22666505 neutral - 99-01 R GM# 22617656 - 99-01 L GM# 22617657 - 02-03 R GM# 22666506 - 02-03 L GM# 22666507 Oak - 99 R GM# 22617658 - 99 L GM# 22617659 8 Upper trim panel w/o speaker pewter - 99-01 R GM# 22614772 - 99-01 L GM# 22614773 neutral - 99-01 R GM# 22614770 - 99-01 L GM# 22614771 Oak - 99 R GM# 22614774 - 99 L GM# 22614775 w/speaker pewter - 99-03 R GM# 22695596 - 99-03 L GM# 22695597 neutral - 99-03 R GM# 22695594 - 99-03 L GM# 22695595 Oak - 99 R GM# 22614766 - 99 L GM# 22614767 9 Switch panel Manual windows - 99-01 R GM# 22658261 - 99-01 L GM# 22658257 - 02-03 R GM# 22663002 - 02-03 L GM# 22663003 power windows - 99-01 R 22658260 - 99-01 L GM# 22658258 - 02-03 R GM# 22663004 - 02-03 L GM# 22663005 10 retainer - 99-03 B GM# 22603516 11 switch bezel - 99-03 included in switch panel 12 mirror switch - 99-00 GM# 12369209 - 01-03 GM# 22624805 13 Lock switch - 99-00 B GM# 22657207 - 01-03 B GM# 22624806 14 Window switch - 99-02 R GM# 22591937 - 99-02 L GM# 22588178 -03 not listed 15 trunk switch - 99-01 GM# 22601764 - 02-03 GM# 22624803 16 Reflector - 99-03 B GM# 22612756
__________________
1999 Grand Am SS 3.4 OHV
|
|
#2
02-02-2007, 12:09 PM
|
||||
|
||||
|
Re: 99-03 Grand Am parts : Body & Structure/Door&Components/ Trim & glass
Rear Door & components
 Door & components 1 door shell - 99-01 R GM# 88950723 - 99-01 L GM# 88950724 - 02-03 R GM# 22675876 - 02-03 L GM# 22675877 anchor plate door hinge - 99-03 B GM# 22643346 2 Outer Panel - 99-03 R GM# 22643606 - 99-03 L GM# 22643607 3 Reinforce bar Inner & outer - 99-03 included in door shell 4 support bar - 99-03 included in door shell 5 Weatherstrip on Body pewter - 99-03 B GM# 22626570 neutral - 99-03 B GM# 22626572 Oak - 99 B GM# 22614288 Exterior Trim  1 Seal strip, upper window frame GT - 99-03 R GM# 22633026 - 99-03 L GM# 22633027 SE - 99-03 R GM# 22701126 - 99-03 L GM# 22633025 2 Belt weatherstrip GT - 99-03 R GM# 22682286 - 99-03 L GM# 22633015 SE - 99-03 R GM# 22682284 - 99-03 L GM# 22682283 3 Applique - 99-03 R GM# 22670112 - 99-03 L GM# 22670113 4 bolt - 99-01 GM# 12337991 - 02-03 GM# 10169777 Body side molding 5 GT - 99-03 R GM# 12365264 - 99-03 L GM# 12365265 6 SE - 99-02 R GM# 12365276 - 99-02 L GM# 12365277 primed - 03 R GM# 88898963 - 03 L GM# 88898964 Red - 03 R GM# 22615644 - 03 L GM# 22615645 Glass & Hardware (rear dr) 1 Moveable glass GM - 99-03 R GM# 22689008 - 99-03 L GM# 22689007 NAGS - 99-03 R DD09437GTY - 99-03 L DD09438GTY 2 Run channel w/fixed glass GM - 99-03 R GM# 22695294 - 99-03 L GM# 22695295 NAGS - 99-03 R DV09439GTY - 99-03 L DV09440GTY 3 Retainer - 99-03 R GM# 22612650 - 99-03 L GM# 22612651 3 Belt w'strip - 99-03 R GM# 22615490 - 99-03 L GM# 22615491 5 Regulator Manual windows - 99-03 R GM# 22683776 - 99-03 L GM# 22683775 Power windows - 99-03 R GM# 22683778 - 99-03 L 22683777 6 Window handle - 99-03 B GM# 22648611 7 Cover plate - 99-03 GM# 20529400 8 water deflector - 99-02 R GM# 22615264 - 99-02 L GM# 22615265 - 03 R GM# 22694116 - 03 L GM# 22694117 Lock & Hardware -  rear 1 Lock - 99-03 R GM# 16633860 - 99-03 L GM# 16633861 2 Lock actuator - 99-02 R GM# 25664287 - 99-02 L GM# 25664288 -03 not listed 3 Striker - 99-03 B GM# 16629888 4 spacer - 99-03 GM# 16621670 5 anchor plate - 99-03 B GM# 22645208 6 bolt - 99-03 GM# 9442471 Lock rod 7 to inside handle - 99-03 R GM# 22609612 - 99-03 L GM# 22609613 8 to lock - 99-02 R GM# 22619618 - 99-02 L GM# 22609609 9 to outside handle - 99-03 B GM# 22611345 10 clip - 99-03 GM# 16675980 11 Handle inside grey - 99-03 R GM# 22616252 - 99-03 L GM# 22616253 neutral - 99-03 R GM# 22616254 - 99-03 L GM# 22616255 Oak - 99 R GM# 22616256 - 99 L GM# 22616257 12 Handle, outside - 99-03 R GM# 22615216 - 99-03 L GM# 22615217 13 Hinge upper - 99-03 R GM# 22615858 - 99-03 L GM# 22615859 lower - 99-03 R GM# 22615858 - 99-03 L GM# 22615859 14 Door check - 99-01 B GM# 22664288 - 02-03 B GM# 22675063 15 gromet - 99-01 GM# 22658739 - 02-03 GM# 22602301 16 Jamb switch - 99-03 B GM# 22600228 Interior Trim  1 Door trim panel Cloth - 99 R GM# 22612126 - 99 L GM# 22612127 - 00-03 R GM# 22629054 - 00-03 L GM# 22629055 leather - 99 R GM# 22612130 - 99 L GM# 22612131 - 00-03 R GM# 22629056 - 00-03 L GM# 22629057 2 retainer - 99-03 GM# 22607698 3 absorber - 99-03 R GM# 22643136 - 99-03 L GM# 22643137 4 Pull handle pewter - 99-03 R GM# 22655514 - 99-03 L GM# 22655515 neutral - 99-03 R GM# 22646410 - 99-03 L GM# 22646411 Oak - 99 R GM# 22655520 - 99 L GM# 22655521 bracket - 99-03 R GM# 22656004 - 99-03 L GM# 22656005 5 Handle bezel Grey - 99-01 R GM# 22617662 - 99-01 L GM# 22617663 - 02-03 R GM# 22666508 - 02-03 L GM# 22666509 neutral - 99-01 R GM# 22617664 - 99-01 L GM# 22617665 - 02-03 R GM# 22666510 - 02-03 L GM# 22666511 Oak - 99 R GM# 22617666 - 99 L GM# 22617667 6 switch panel manual windows - 99-00 R GM# 22612662 - 99-00 L GM# 22612659 - 01-03 R GM# 22625091 - 01-03 L GM# 22625092 power windows - 99-00 R GM# 22658262 - 99-00 L GM# 22658264 - 01-03 R GM# 22663009 - 01-03 L GM# 22663010 7 retainer - 99-03 B GM# 22603516 8 Window switch - 99-00 B GM# 22588399 - 01-03 B GM# 22624810 9 Reflector - 99-03 B GM# 22612756 GLASS  Back Glass GM , w/o Onstar 2 door - 99-03 GM# 22613642 4 door - 99-03 GM# 22613645 GM, w/Onstar 2 door - 02-03 GM# 22613642 4 door - 02-03 GM# 22613645 NAGS 2 door non-heated - 99-03 DB09434GTN heated w/o antenna - 99-03 DB09433GTN heated W/ antenna - 99-03 DB09432GTN 2 Reveal molding 2 door - 99-03 GM# 22624828 4 door - 99-03 GM# 22624826 Quarter panel  2 door Quarter panel & Comp 1 Quarter panel - 99-02 R GM# 22654826 - 99-02 L GM# 22654827 - 03 not listed 2 upper reinf - 99-03 R GM# 22640760 - 99-03 L GM# 22640761 3 Striker reinf - 99-03 R GM# 22612566 - 99-03 L GM# 22612567 4 fuel door - 99-03 GM# 22685677 5 Pressure valve - 99-03 GM# 10440792 Exterior Trim  1 Body side mldg SE - 99-02 R GM# 12365274 - 99-02 L GM# 12365275 2 retainer clip - 99-03 GM# 10246149 3 Applique - 99-03 R GM# 22668052 - 99-03 L GM# 22668053 4 bolt - 99-03 GM# 11509231 5 nut - 99-03 GM# 22612801 Glass  Side fixed 1 Glass GM GT - 99-03 R GM# 22616112 - 99-03 L GM# 22616223 SE - 99-02 R GM# 22615168 - 99-02 L GM# 22615169 NAGS black frame - 99-03 R DQ09430GTY - 99-02 L DQ09431GTY black, chrome - 99-03 R DQ09868GTY - 99-03 L DQ09869GTY 2 Adhesive Kit - 99-03 GM# 12346392 INNER STRUCTURE  1 inner qtr panel - 99-01 R GM# 22654834 - 99-01 L GM# 22654835 - 02 R GM# 22676652 - 02 L GM# 22654835 Wheelhouse 2 outer - 99-03 B included with inner qrtr panel 3 inner - 99-02 R GM# 22628414 - 99-02 L GM# 22625967 - 03 R GM# 22699920 - 03 L GM# 22699921 4 Extension - 99-03 R GM# 22652832 - 99-03 L GM# 22612841 5 Sear belt anchor - 99-03 B GM# 22646662 Interior Trim  1 Upper qtr trim neutral - 99-03 R GM# 22618626 - 99-03 L GM# 22618627 grey - 99-03 R GM# 22697464 - 99-03 L GM# 22697465 Oak - 99-03 R GM# 22618630 - 99-03 L GM# 22618631 2 clip - 99-03 B GM# 16662182 3 Lower qtr trim w/insert Neutral - 99 R GM# 22614862 - 99 L GM# 22614861 grey - 99 R GM# 22614860 - 99 L GM# 22614861 w/o insert neutral - 99-03 R GM# 22614862 - 99-03 L GM# 22614863 Grey - 99-03 R GM# 22614860 - 99-03 L GM# 22614861 Oak - 99 R GM# 22614864 - 99 L GM# 22614865 4 upper retainer - 99-01 B GM# 15706048 - 02-03 B GM# 10290472 5 lower retainer type 1 - 99-01 B GM# 16662182 type 2 - 99-01 B GM# 10290472 - 02-03 B GM# 16662182 Quater Panel 4 Door  1 quater panel - 99-03 R GM# 22654830 - 99-03 L GM# 22654831 2 brace - 99-03 R GM# 22652842 - 99-03 L GM# 22652843 3 Fuel door - 99-03 GM# 22685677 4 Pressure valve - 99-03 GM# 10440792 Exterior trim  1 body molding SE - 99-02 R GM# 12365272 - 99-02 L GM# 12365273 2 retainer clip - 99-02 GM# 10246149 Inner Structure  1 inner qtr panel - 99-02 R GM# 22654840 - 99-02 L GM# 22654841 - 03 not listed 2 Outer wheelhouse - 99-01 order by color - 02 R GM# 22658754 - 02 L GM# 22646657 3 inner wheelhouse - 99-02 R GM# 22628414 - 99-02 L GM# 22625967 - 03 R GM# 22699920 - 03 L GM# 22699921 4 brace - 99-03 R GM# 22612754 - 99-03 L GM# 22612755 5 Extension - 99-03 R GM# 22652832 - 99-03 L GM# 22612841 Interior Trim  1 Upper qtr trim neutral - 99-03 R GM# 22663338 - 99-03 L GM# 22663339 pewter - 99-03 R GM# 22663336 - 99-03 L GM# 22663337 Oak - 99 R GM# 22615042 - 99 L GM# 22615043 2 Clip - 99-03 B GM# 16662182
