Ford Escort RS1800

[Boreham]

Well that turned out to be a can of worms

[Ford Escort mk 1]

Originally Posted by Boreham

Well that turned out to be a can of worms

It is when we are talking about Escorts

[afxracing]

[quote=Ford Escort mk 1;7154689]AFX, these rims are used on gravel too


You are correct Kimmo these wheels were used on mixed surfaces but I think they are generally considered tarmac wheels.

[afxracing]

Does anyone have a good photo of the tread pattern of a Dunlop tarmac tire? I know they used multiple different tread patterns and even slicks (no tread pattern) when allowed. I am looking for something with very little pattern that was most common.

[afxracing]

Originally Posted by generationx

I sit corrected. Good research work!

Thanks for keeping an eye on me generationx I want to get this build as correct as I can within my skill level and budget.

[malscar]

[quote=afxracing;7154707]

Originally Posted by Ford Escort mk 1

AFX, these rims are used on gravel too


You are correct Kimmo these wheels were used on mixed surfaces but I think they are generally considered tarmac wheels.

I agree, they were more likely to use a gravel rim on tarmac than the tarmac rim on the dirt. Very rarely do you see a period photo of the cars with the tarmac wheels on dirt. They may do so today, but not back in the '70s and '80's.

[afxracing]

Originally Posted by Ford Escort mk 1

It is when we are talking about Escorts

I hope I survive this build

[Ford Escort mk 1]

Originally Posted by afxracing

Does anyone have a good photo of the tread pattern of a Dunlop tarmac tire? I know they used multiple different tread patterns and even slicks (no tread pattern) when allowed. I am looking for something with very little pattern that was most common.

AFX,

Do you have this book?


If you do, take a look of page 188, there is a pic where may be the tires you are looking?
same book has a nice pic of Pirelli tarmac tires, page 7

Hre is a link if you want to buy the book
http://www.amazon.com/Works-Escorts-.../dp/1906133441

Originally Posted by afxracing

I hope I survive this build

You will survive

Kimmo

[afxracing]

I do have that book but I need an internet image to send to the CAD designer. I am going with this tread pattern. The pattern was developed for rally cars in the 1970s



Although it is a Michelin pattern and I know the works team raced on Dunlops and later Pirellis it looks a lot like this period photo.

[afxracing]

Adding more detail to the front strut mounts including the brackets for the strut brace.

[afxracing]

Went a little different direction on the tread pattern based on this period photo.

[Ford Escort mk 1]

Hello,

a good choice

Nice fix you have made on the strut brace.


Kimmo

[Boreham]

Fantastic..!!
When your down to a thread pattern.. There's not much left to fault :-)

[afxracing]

Here is the set.

[stevenoble]

Those wheels look fantastic..!!
