86 caprice. 305 to 350. drive shaft lengths?

[m3gas3th]

i am going to put a 350 with 350 turbo trans into my 86 caprice classic that has a 305 with 700r4 and i was wondering if i would have any problems with the lengths of the drive shafts.

i dont know much about cars but i asked the guy putting the engine in if there would be any problems doing it and if i would need extra money to make the transition and he said i might want to find out if the drive shafts are the same length.

thanks for reading, i appreciate any advice,
and have tons more questions if you have time.

[toddman67]

Take a measurement on both transmissions from bell housing to tail shafts, that should be a good indicator.

[m3gas3th]

thanks todd, that sounds like a last minute, last resort option.. but if it comes down to it thats what i will do! and i appreciate your help!!

BUT, i still have to drive this thing!! and id hate to tear the motor out and it not be the same!! anyone know for sure??

[silicon212]

Originally Posted by m3gas3th

i am going to put a 350 with 350 turbo trans into my 86 caprice classic that has a 305 with 700r4 and i was wondering if i would have any problems with the lengths of the drive shafts.

i dont know much about cars but i asked the guy putting the engine in if there would be any problems doing it and if i would need extra money to make the transition and he said i might want to find out if the drive shafts are the same length.

thanks for reading, i appreciate any advice,
and have tons more questions if you have time.

You will need to get a driveshaft for the TH2004R trans to make it work, provided your TH350 has the common length 6" tailshaft.

[toddman67]

Silicon212 brings up a good point, spline size etc. If the 700r4 is good? keep it in the car. Otherwise the web site below might help.





BTO Links

</SPAN>








It has come to our attention that there are some companies out there riding our coat tails! Employing such tactics as registering sites with our name .net, or .org Companies that in the past have copied graphics off of our website and posted them as their own. Mimicing our prices, our "levels" and even going as far as to copy our information WORD FOR WORD off of our site and using it as their own. To our customers, dont be fooled by cheap imitations. There is only one bowtieoverdrives.com, only one 700R4.com We have been in business a long time and have been the leader in GM rear wheel drive transmissions and truly make the finest overdrives anywhere. We havent paid much attention to the goings on of other companies as we dont get our information from them. We dont need to search anyone elses site for information on transmissions we are the experts in. For example, if you were to go to www.bowtieoverdrives.net it would redirect you to another site, one that is in NO WAY affiliated with Bowtie Overdrives. In our opinion this is a shady way to get customers who are looking for quality Bowtie products to stumble into another shop and be fooled into thinking they are getting the best.


Welcome to Bowtie Overdrives, home of the worlds finest GM Automatic Overdrive Transmissions. Whether you are looking for the evenly geared 2004R or the aggressive first gear (3.06:1) in the 700R4, you are in the right place. Not only will an Overdrive Transmission improve your performance, but it will reduce your fuel consumption by up to 33%. We have everything you need to make the conversion from the older TH350, TH400, and Powerglide to the newer Overdrives. If you are looking to go with more than 500 horsepower, maybe the 4L80E is the right transmission for you. Our knowledgeable staff will be able to point you in the right direction. We offer free tech service during normal business hours, if you miss us leave a message and you will be hearing from us soon.


Local time in Hesperia, California is

Business Hours are Monday-Friday 8AM-5PM

BTO AffiliatesWise Transmissions
Hat Racing
San Diego Gear and Axle
Race Street Rally
Articles about BTOCar Craft
Street Rodder
Rod & CustomShow SchedulePomona Swap Meet

• June 7th
• August 16th
• October 18th
• December 6th

For all events we'll be located at Road 16,
Space #'s 21, 23, 25, 27
HI-Performance Swap Meet Long Beach Veterans Stadium

• May 10th
• June 14th
• July 12th
• August 9th
• September 13th
• October 11th
• November 8th
• November 29th
• Spaces TBA

Good Guys Events

Hot August Nights

• August 5th - 9th

Main Page
About Us
Contact Us
Online Catalog
Customer Login
Product Instructions
Warranty Policy
Speedo Calculator 700R4
Speedo Calculator 2004R
700R4 Information
·700R4 Catalog
·700R4 FAQ
·700R4 Transmission Site

2004R Information
·2004R Catalog
·2004R FAQ
·2004R Transmission Site


4L80E Transmissions
4L60E Transmissions
Extreme Duty Parts
TV System

<A class=smallLinks href="http://www.bowtieoverdrives.com/">Main Page | <A class=smallLinks href="http://www.bowtieoverdrives.com/about.shtml">About Us | <A class=smallLinks href="http://www.bowtieoverdrives.com/contact.shtml">Contact Us | <A class=smallLinks href="http://www.bowtieoverdrives.com/catalog/index.php">Online Catalog | <A class=smallLinks href="http://www.bowtieoverdrives.com/login">Customer Login | NaN
<A class=smallLinks href="http://www.700r4.com/" target=_self>700R4 Transmissions | <A class=smallLinks href="http://www.2004r.com/" target=_self>2004R Transmissions | <A class=smallLinks href="http://www.bowtieoverdrives.com/catalog/catalog.php?Action=GETSUBCAT&CATID=ZA" _Blank?>4L80E Transmissions <A class=smallLinks href="http://www.bowtieoverdrives.com/catalog/catalog.php?Action=GETSUBCAT&CATID=ZB" _Blank?>4L60E Transmissions | <A class=smallLinks href="http://www.bowtieoverdrives.com/catalog/catalog.php?Action=GETSUBCAT&CATID=N">Extreme Duty Parts | <A class=smallLinks href="http://www.tvmadeez.com/" target=_self>TV System | Cooling Lines
Copyright © 2000-2006 Bowtie Overdrives
700r42004r4l80econverterscrossmemberstv systemtv cablecooling linesoverdrivegm automatictorque convertertransmission

[m3gas3th]

todd, the 700r4 is good. i think the 305 has bad rings or something ( vibrating, lots of smoke from exhaust) i took it to a shop and they said the motor had oil leaking into the # 6 head. so im upgrading.

my boss is selling me the 350 with the 350 turbo trans on it with a shift kit for only 300 bucks. i know it runs good, it was in one of the work trucks until the frame bent. SO, is the 700r4 really all that or what? or should i sell it and get the 350 and trans for basically free??

i understand the 305 and 700r4 is better gas mileage and all that, but i want power! theres always hydrogen systems later..

[CD Smalley]

700 has a low first gear, plus the over drive. You be much better off in the long run with the 700.

[m3gas3th]

so u think the 700r4 would be better on the 350 rather than the 350turbo? and if so, would it go in there with no problem?

[silicon212]

Originally Posted by m3gas3th

so u think the 700r4 would be better on the 350 rather than the 350turbo? and if so, would it go in there with no problem?

Absolutely. Look at my sig - my 350 has been augmented for more torque than stock and the 700R4 (which, might I add was pulled from an '86 with 305 in '06) is loving every minute of it.

The 700R4 is the logical choice - it offers the best 'off the line' performance of any of them, and has overdrive, and requires absolutely no modification of any other systems to work.

[CD Smalley]

+1 to Silicon's last comment. Use the 700R4.

[toddman67]

I agree, Keep the 700r4 in place and just swap the engine. Less work!

Less is more.

[m3gas3th]

saaweeeet.. thanks guys. i guess that pretty much wraps that question up. anyone wanna buy a transmission? hahaa.
